Molding Equipment
- Kloster No-Bake Molding System - 40" x 48" 14"/14"
- Manual and Floor No-Bake Molding
- 2 - Hunter 10 C automated molding machines - 14" x 19" 4"/5"
- 1 - Hunter 20 automated molding machine - 20" x 24" 6"/8"
- 2 - Osborn 730 RJW Jolt Squeeze machines
- 2 - Cold Box core blower, plus 3 small manual shell core machines
- 4 - PermCast (Eaton) -Cast Iron Permanent Molding Machines
Melting Equipment
- 7-Induction melting Machines, 2,000 # crucibles, one 8,800 #
- 2-Cupola melting Units, 36" D
Measuring equipment and others
- 3 Heat Treat furnace for parts up to 4 Tons
- DV-4 Baird Spectrometer
- Bruker Q8 Magellan Spectrometer
- QuikLab Carbon Determinator
- Bruker G4 Icarus HF Carbon an Suplhur Determinator
- Brown and Sharp CMM Validator 300
- IMS Premier 1000 CMM
- Sand analysis Lab
- Magnetic Particle Inspection
- Hardness tester
- Olympus metallographic microscope with image analyzer
- Shimadzu Tensile Testing Machine
Machining Equipment
| CNC TURNING |
GIDDINGS & LEWIS
65 SERIES VTL |
WARNER & SWASEY SC-28 |
MORI SEIKI
SL-3 |
MAZAK NEXUS QUICKTURN
300-II |
HAAS ST10 |
HAAS ST30 |
HAAS ST40 |
| Work Centers |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| No. of tools |
5 |
6 |
12 |
12 |
12 |
12 |
12 |
| Swing |
60" |
28" |
17" |
24" |
16 1/4" |
31 1/4" |
34 1/2" |
| Mach. Diam |
52" |
24" |
10" |
16" |
14" |
21" |
25 1/2" |
| Power (HP) |
50 |
60 |
10 |
35 |
15 |
30 |
40 |
| Speed (RPM) |
272 |
851 |
4,000 |
4,000 |
6,000 |
3,400 |
2,400 |
| Z-Axis Travel |
19" |
41" |
16" |
28.8" |
14" |
26" |
44" |
| CNC MILLING |
HAAS VF8 |
MAZAK NEXUS
510-CII |
LEBLOND MAKINO MC86 |
HAAS VF6 |
HAAS EC1600 |
| Work Centers |
1 |
1 |
2 |
1 |
1 |
| X-Axis Travel |
64" |
41.3" |
32" |
64" |
64" |
| Y-Axis Travel |
40" |
20" |
25" |
32" |
50" |
| Z-Axis Travel |
30" |
20" |
25" |
38" |
32" |
| Taper |
CAT 50 |
CAT 40 |
CAT 50 |
CAT 50 |
CAT 50 |
| Table Length |
64" |
51.1" |
24.8" |
64" |
64" |
| Table Width |
36" |
21.6" |
24.8" |
28" |
36" |
| Spindle Speed (RPM) |
5,000 |
12,000 |
4,000 |
7,500 |
6,000 |
| Spindle Power (HP) |
30 |
25 |
20 |
30 |
30 |
| ATC |
30 |
30 |
120 |
30 |
30 |
| 4th axis equipped |
YES |
N/A |
YES |
N/A |
SI |
| Pallet Changer |
N/A |
N/A |
2 pallets |
N/A |
N/A |
Grinding
- Thompson Grinder, 24” x 96” table
- Blanchard Grinder 18-30, 30" table
- Blanchard Grinder 18-36, 36" table
|
|
|
|
